Pillow Bag Machines
Brief Description
- vertical pouch packaging machine of the newest generation
- developed for high availability and reliability
- for pillow bags up to 5 kg, jumbo bags up to 15 kg or dip-doys (doypacks in 2 lanes)
- servo-driven sealing and film pulling
- vertical operation with continuous film transport
- modular structure
- easy to combine with upstream and downstream machines
- applicable for various products
- easy to use and maintain
- machine frame and control cabinet made of stainless steel
Options
- combinable with dosing systems (e.g. feed pumps, multiplehead scales or auger fillers)
- combinable with control mechanisms (e.g. metal detectors)
- airless pouches
- Zip
- Euro-hole
- easy opening features
| Technical Data (Basic Machine) |
SB-L |
| bag width: |
max. 400 mm |
| bag length: |
max. 550 mm |
| lanes: |
1 - 2 |
| performance - thermal sealing: |
up to 60 / 120 ppm 1 |
| performance - ultrasonic sealing: |
up to 40 ppm 1 |
| sealing force: |
max. 10,000 N |
| film reel width: |
max. 820 mm |
| film reel diameter: |
max. Ø 600 mm |
| electrical service: |
400 VAC, 50 Hz, approx. 19 kVA |
| dimensions (l - w - h): |
2,420 mm x 1,700 mm x 2,270 mm |
| weight: |
approx. 2,000 kg |
| PLC: |
Schneider Electric 2 |
1...dependent on material, product, sachet dimensions & dosing system
2...other PLC's on request
Pillow Bag Machine Machine SB-L (formerly SB 800) in Action
